Réticule: MIL - G4Ai illuminé
Tourelles: Hunting
Parallaxe: 10yds - ?
1 click = 0,1 MRAD
Tube: 30mm
Réticule: MIL - G4Ai illuminé
Tourelles: Hunting
Parallaxe: 10yds - ?
1 click = 0,1 MRAD
Tube: 30mm
OPTICAL DATA
Magnification (High) 12X
Magnification (Low) 3X
Objective Diameter (mm) 56mm
Outer dia. Objective (mm) 65mm
FOV (min.mag)(ft/100yds) 36.7
FOV (max.mag)(ft/100yds) 9.2
Eye relief (in) 3.8'' - 3.5''
Exit Pupil (Max mag.) (mm) 4.5mm
Exit Pupil (min. mag.) (mm) 18.6mm
Diopter Range (dpt) +2/-2
Parallax Adjustment 10yds - infinity (100yds parallax free)
Coating Fully Multi-coated
MECHANICAL DATA
Tube Construction One-piece tube, aircraft aluminum
Elevation Adjustment (value per click) 0.1 mrad
Windage Adjustment (value per click) 0.1 mrad
Turret Style (Elevation) Low profile, tooless resettable zero
Turret Style (Windage) Low profile, tooless resettable zero
Travel Per Rotation 6 mil
Elevation adj. range >= 15 mil
Windage adj. range >= 15 mil
Eye Piece Diameter (in) 1.73''
Eye Piece Diameter (mm) 44mm
Eye Piece Length (in) 2''
Eye Piece Length (mm) 51.2mm
Mounting Length rear (mm) 58mm
Mounting Length front (mm) 48mm
Tube Dia. (mm) 30mm
Length (in) 13.46''
Length (mm) 342mm
Weight (g) 772g
Weight (oz) 27.23oz
Surface Finish Matte Black
ENVIRONMENT DATA
Functional temperature -20 ~ 50 degree celcius
Storage temperature -20 ~ 50 degree celcius
Submersion tightness JIS 7
RETICLE DATA
Reticle MIL-G4Ai12X
Calibrated Ranging Power 12X
Focal plane Second
Illumination 6 Steps illumination with off setting in between
